Bendi Sonde
Flexible 512 Hz locating sonde designed for accurate tracing of non-metallic pipes and ducts, including tight bends and corners.
Key Features:
✔️ 512 Hz operating frequency compatible with standard sonde locators
✔️ Three-section flexible construction improves navigation through bends
✔️ Detectable to depths of up to 19 ft (6 m) in typical locating conditions
✔️ Slim 23 mm diameter allows use in narrow conduits and ducts
✔️ Compact 478 mm length maintains signal stability in confined spaces
✔️ Self-contained battery power with no external cables required
✔️ Supplied with M10 male end cap for secure accessory connection
✔️ Suitable for locating and mapping non-metallic underground utilities
Bendi Sonde
The Bendi Sonde is a three-section locatable probe designed for navigating complex pipe and duct systems. It measures 0.9 x 18.8 inches (23 x 478mm) and offers detection capability up to 19 feet (6 meters) depth. The unit includes an M10 male end cap for secure attachment to compatible rod systems. Its segmented construction allows angular movement through bends and junctions that rigid probes cannot traverse.
Each section features a flexible joint that permits directional changes while maintaining signal integrity. The sonde transmits a 512Hz frequency, detectable by standard cable and pipe locators. Constructed from durable composite materials, it weighs approximately 150 grams. The orange protective casing ensures visibility during retrieval operations. This modular design distributes stress across multiple pivot points rather than concentrating force at a single bend location.
Plumbers use the Bendi Sonde to trace blocked drain lines through multiple directional changes in residential and commercial buildings. HVAC technicians deploy it inside ventilation ductwork to map hidden routes before wall penetration work begins. Utility contractors attach it to push rods for locating underground non-metallic conduits where traditional electromagnetic detection fails. Building inspectors utilize it to verify proper pipe installation behind finished walls without destructive investigation.
Tactical Supply Pakistan provides specialized equipment for professionals who require reliable location tools in demanding field conditions. The company maintains rigorous quality standards across its product inventory.
Can the Bendi Sonde navigate 90-degree elbows in standard PVC drainage pipes?
Yes, the three-section articulated design allows passage through standard 90-degree elbows in 4-inch and larger diameter PVC pipes. The segmented construction flexes sequentially as each section enters the bend.
