Smart IR Med-Evac Landing Zone Kit
A radio-linked LED kit providing visible and infrared guidance for safe, obstacle-free med-evac landing zones under all operational conditions.
Key Features:
✔️ Includes 5 radio-linked flares to mark landing zones with precision
✔️ Visible green and infrared LEDs enhance pilot visibility amid red, blue, and white emergency lights
✔️ Flashes in unison to create an easily identifiable landing “constellation”
✔️ Flexible layout: 100-foot square or inverted “Y” configuration with wind direction indicator
✔️ Any flare can control the group, allowing switching between visible and IR modes with one button
✔️ Low-profile, lightweight units resist rotor wash and remain stable during helicopter approach
✔️ Available in rechargeable or alkaline battery configurations for operational flexibility
✔️ Rapid deployment and retrieval suitable for emergency and tactical med-evac scenarios
Smart IR Med-Evac Landing Zone Kit
The Smart IR Med-Evac Landing Zone Kit contains five radio-synchronized flares, each measuring 3.5 inches in diameter with a low-profile height of 1.5 inches to resist rotor wash displacement. Each unit houses dual LED arrays: 12 visible green LEDs operating at 525nm wavelength and 12 infrared LEDs emitting at 850nm for night vision goggle compatibility. The flares communicate via 2.4GHz radio frequency, maintaining synchronization across distances up to 350 feet. Rechargeable versions use lithium-ion cells providing 48 hours of operation, while alkaline models run on three AA batteries for 30 hours continuous use.
The polycarbonate housing withstands impact forces and features magnetic mounting bases with rubberized grips for ground placement. Each flare operates as a master controller, allowing any unit to switch the entire network between visible green and infrared modes instantly. The devices establish either a 100-foot square perimeter with four corner markers and one directional indicator, or an inverted Y-pattern configuration for obstacle identification. Flash synchronization occurs within 50 milliseconds across all units, creating a distinct constellation pattern visible to pilots at altitudes up to 1,500 feet. Operating temperature range spans -4°F to 131°F.
Army medevac helicopter crews rely on the Smart IR Med-Evac Landing Zone Kit during covert casualty extractions where visible light compromises operational security in hostile territory. Marine Corps forward surgical teams mark emergency landing zones at field hospitals using infrared mode during blackout conditions. Air force pararescue units deploy these kits for night infiltration missions requiring NVG-compatible ground markers. Special operations forces use them to designate extraction points without alerting enemy forces to helicopter approach vectors.
Tactical Supply Pakistan offers aviation support equipment designed for tactical medical evacuation operations in contested environments.
Do infrared LEDs work with all night vision device generations?
Yes. The 850nm wavelength remains compatible with Generation 1 through Generation 3 night vision goggles and modern digital NVG systems used by military forces.
