Radar-Guided Directed Energy Defense System
Radar-Guided Directed Energy Defense System is a radar-guided hard-kill laser solution delivering fast, precise, and silent drone neutralization for permanent protection of high-value assets.
Key Features:
✔️ Radar-guided laser hard-kill interception
✔️ Small drone detection up to 3.5 km
✔️ Large UAV detection up to 10 km
✔️ Sub-2-second target lock-on
✔️ High tracking accuracy (≤15 μrad RMS)
✔️ Wide coverage: 360° azimuth, −20° to +80° elevation
✔️ Rapid multi-target engagement switching
✔️ Silent, low-collateral neutralization
✔️ IP66-rated for all-weather deployment
Radar-Guided Directed Energy Defense System
The Radar-Guided Directed Energy Defense System (SRD200) is a hard-kill laser countermeasure module with a total weight under 830 kilograms. The main unit measures 1200mm by 1200mm by 2500mm, accompanied by a separate chiller unit. It operates within a temperature range of -40 to +55 degrees Celsius and has an IP66 environmental rating. The system’s field of view covers -180 to +180 degrees in azimuth and -20 to +80 degrees in elevation. Tracking accuracy is within 15 microradians root mean square.
This system detects small FPV drones at 3.5 kilometers and large fixed-wing UAVs at 10 kilometers. It tracks targets moving between 1 and 100 meters per second. The target lock-on time is two seconds or less. Engagement dwell time varies from 3-5 seconds for FPV drones to 8-15 seconds for rotary-wing models. The system can sustain a maximum continuous engagement time of 500 seconds. The transition time between engaging two separate targets is two to five seconds.
The Radar-Guided Directed Energy Defense System provides a final layer of physical interception in a multi-layered defense. It is deployed at permanent, high-value sites to neutralize confirmed drone threats with minimal collateral risk. Operators use it to silently disable hostile drones through targeted energy deposition, causing critical system failure. This system is employed when electronic warfare measures are insufficient or when a permanent, reusable hard-kill solution is required.
Tactical Supply Pakistan specializes in supplying this advanced directed-energy defense technology. We ensure our clients receive integrated systems capable of delivering precise, cost-effective drone neutralization for strategic asset protection.
What is the primary advantage of a laser-based countermeasure over kinetic interceptors?
It offers a virtually unlimited magazine depth, low per-engagement cost, and silent, precise engagement with minimal risk of collateral damage from falling debris.
