Epithelial Cells Intelligent System
Portable forensic imaging system for precise detection, visualization, and extraction of trace DNA and epithelial cells from diverse evidence surfaces.
Key Features:
✔️Dual-rate optical magnification: low (0–100x) for search and positioning, high (100–500x) for detailed observation
✔️Multi-spectral excitation: 445 nm laser, 365 nm LED, 10 W white and yellow LEDs for versatile evidence detection
✔️Wireless or wired module connection for flexible operation in confined or complex environments
✔️Real-time search, location, observation, and judgment of trace DNA and epithelial cell carriers
✔️Integrated autofocus macro and micro imaging modules for lossless magnification
✔️Anti-cross contamination measures with UV inactivation ring and lysis cleaning solution
✔️Three-level dimming with precise, high-purity wavelength selection for small biological specimen detection
✔️Compact, lightweight, and portable design (1454 g; 193×102×143 mm) for on-site forensic use
Epithelial Cells Intelligent System
Epithelial Cells Intelligent System weighs 1,454g and measures 193mm x 102mm x 143mm in a portable integrated design. It features dual-rate optical magnification with autofocus capability, providing 0-100x low magnification for search and positioning, and 100-500x high magnification for observation and judgment. The device operates with a 445nm 10W laser, 365nm 10W LED, white LED 10W, and yellow LED 10W light sources. Each wavelength offers three dimming levels: weak, medium, and strong for intensity adjustment during evidence examination.
This system enables wireless module separation from the host unit, allowing operation in confined spaces or on special objects. The high-purity spectral module detects invisible trace DNA evidence on various carrier materials including paper, cotton, nail samples, and textile surfaces. Continuous lossless magnification allows real-time extraction without switching between search and collection modes. An anti-contamination system includes UV inactivation protection and lysis cleaning solution; after use, 254nm UV light irradiates the outer shell and inner walls to eliminate trace adhesions for safe reuse across multiple cases.
Forensic DNA laboratories deploy the Epithelial Cells Intelligent System to locate cellular material on sexual assault evidence and personal belongings. Military investigative units apply it to examine equipment and documents for touch DNA from unauthorized handlers. Counterintelligence agencies use the wireless functionality to process sensitive materials in secured rooms where standard equipment cannot enter. Border security teams utilize it to extract epithelial cells from contraband packaging that links suspects to smuggling operations.
Tactical Supply Pakistan provides DNA collection technology that reduces contamination risks during evidence processing. Their equipment enables Pakistani forensic teams to maintain international chain-of-custody standards.
Does magnification switching disrupt sample positioning?
No, the continuous magnification system maintains focal point registration during zoom transitions, preventing position loss between search and extraction phases.
