All-Terrain Tracked Multifunctional Transport Vehicle
All-Terrain Tracked Multifunctional Transport Vehicle – A rugged tracked carrier built for reliable transport and rescue missions across extreme terrains.
Key Features:
✔️ Strong diesel engine and wide rubber tracks ensure movement on mud, sand, snow.
✔️ Built to carry equipment, cargo, or personnel with stable balance and power.
✔️ Configurable for transport, logistics, or emergency response tasks.
✔️ Low ground pressure provides grip and stability on uneven surfaces.
✔️ Reinforced steel frame with weather-resistant protection for long-term use.
✔️ Capable of shallow-water travel for added versatility.
✔️ Shock-absorbing suspension and ergonomic controls for smooth handling.
✔️ Operates reliably from –40°C to +50°C in extreme environments.
All-Terrain Tracked Multifunctional Transport Vehicle
The All-Terrain Tracked Multifunctional Transport Vehicle features a dual-unit articulated frame design with independent rubber track systems on all four track assemblies. The vehicle measures 14.2 meters in total length with a 2.5-meter width and 2.8-meter height, delivering a combat weight of 17,000 kg. Its all-powered track configuration uses articulated steering via a swivel joint between units, eliminating the need for differential track speed during directional changes. The chassis incorporates a modular payload structure allowing quick-change functional modules on the rear platform. Engine displacement reaches 12 liters with maximum horsepower delivery supporting extended operations in severe conditions.
The vehicle operates with a maximum road speed of 65 kilometers per hour and amphibious capability at 5 kilometers per hour in water. Its turbodiesel engine generates sufficient torque to maintain a 35-degree maximum gradeability and traverse 25-degree side slopes. The minimum turning radius stands at 7.8 meters, with obstacle-crossing height capability of 1 meter and trench-crossing width of 1.6 meters. Operating temperature range extends from -43 to +50 degrees Celsius. The vehicle carries capacity reaches 6,000 kilograms with a fuel tank holding 250 liters.
Field operations position the All-Terrain Tracked Multifunctional Transport Vehicle across rescue operations, disaster response, remote supply missions, and humanitarian transport in impassable terrain. Organizations deploy it across wetlands, sandy regions, mountainous zones, and post-disaster areas where conventional vehicles fail. Fire departments, emergency services, and military units rely on its modular platform for rapid configuration changes between reconnaissance, transport, medical evacuation, and supply delivery roles.
Tactical Supply Pakistan delivers this vehicle through proven supply channels with on-site support for deployment and maintenance operations. The dual-track architecture and modular design provide exceptional versatility for operations demanding rapid role-switching in hostile or austere environments.
What advantage does the articulated steering system provide over differential steering methods?
Articulated steering allows both track units to maintain forward motion while the swivel joint between them redirects the vehicle, reducing ground pressure distribution stress and track wear during turns.
