Unmanned Ground Vehicle (UGV)
A compact, hybrid-electric Unmanned Ground Vehicle engineered for surveillance, reconnaissance, and hazardous environment operations with modular adaptability and all-terrain mobility.
Key Features:
✔️ Compact hybrid-electric UGV designed for surveillance and reconnaissance.
✔️ Lightweight 32 kg chassis with aluminum-composite construction and rubber tracks.
✔️ Modular payload system supports up to 30 kg of mission-specific equipment.
✔️ Independent suspension with 180 mm ground clearance for smooth terrain handling.
✔️ Operates 6–8 hours continuously with silent low-noise electric drive.
✔️ Achieves 15 km/h speed and climbs 25° slopes under full load.
✔️ Equipped with 360° obstacle detection and SLAM-based autonomous navigation.
✔️ Secure 2 km radio control with automatic return-to-home on signal loss.
✔️ Operates reliably between –15 °C and +45 °C.
✔️ Ideal for surveillance, EOD, CBRN, rescue, and disaster assessment missions.
Unmanned Ground Vehicle (UGV)
The Unmanned Ground Vehicle (UGV) measures 630 millimeters in length, 545 millimeters in width, and 230 millimeters in height with operational weight of 32 kilograms. The chassis uses aluminum-composite construction with rubber tracks providing low ground pressure distribution. Independent suspension with sealed bearing assemblies enables smooth transit across soft terrain. Quick-release mounting brackets support up to 30 kilograms of modular payload equipment including surveillance sensors and communication modules.
Operating parameters deliver six to eight hours of continuous operation through hybrid electric propulsion. Maximum speed reaches 15 kilometers per hour across unprepared terrain with gradeability sustaining 25-degree slopes. Ground clearance measures 180 millimeters with 360-degree obstacle avoidance sensors using simultaneous localization and mapping. Silent electric drive produces minimal acoustic signature. Operating temperature range spans -15 to +45 degrees Celsius. Radio-frequency control maintains 2-kilometer line-of-sight communication with autonomous return-to-home functionality upon signal loss.
Deployed Unmanned Ground Vehicle (UGV) platforms perform border surveillance, explosive ordnance detection, chemical-biological reconnaissance, and urban structure assessment. Search and rescue teams utilize the compact form for confined space exploration within collapsed buildings. Law enforcement agencies deploy the system during building clearance operations. Humanitarian organizations integrate the platform for mine detection support. Disaster response teams conduct damage assessment ahead of personnel entry.
Tactical Supply Pakistan delivers this UGV with integrated sensor packages and field-proven teleoperation controllers. Man-portable design enables rapid transport across extended operational distances without support vehicles.
How does SLAM navigation function without GPS signals in dense urban structures?
The SLAM algorithm combines real-time LiDAR data with inertial measurement readings to build three-dimensional environment models, enabling autonomous navigation through GPS-denied spaces using visual and depth-sensing odometry.
