Passive Spectrum Anti-Drone Detection Radar
A lightweight, covert RF-based detection system that identifies UAVs by analyzing their radio frequency signatures. Designed for rapid deployment and passive surveillance over a 10km detection radius.
✔️ Passive RF detection system (0.02GHz–6GHz range)
✔️ Detection radius: ≥10km
✔️ Response time: ≤1 second
✔️ Tracks over 20 drones simultaneously
✔️ False alarm rate below 5%
✔️ Weighs under 20kg for portable deployment
✔️ Operates on AC220V, <100W power consumption
✔️ Ideal for airports, events, power plants, and secure zones
✔️ Fully passive—no emissions or signal interference
✔️ Can be networked with active countermeasure platforms
Passive Spectrum Anti-Drone Detection Radar
The Passive Spectrum Anti-Drone Detection Radar is a compact, high-performance system engineered to detect and locate unauthorized UAVs by analyzing their radio frequency signatures. Operating within a broad 0.02GHz to 6GHz frequency range, it delivers fast and reliable reconnaissance with a response time of ≤ 1 second. Its passive operation makes it nearly undetectable while enabling real-time direction finding at a minimum detection radius of 10km.
This advanced radar system offers robust performance with the ability to simultaneously track over 20 drones while maintaining a false alarm rate of less than 5%. Designed for portability and ease of deployment, each unit weighs less than 20kg, allowing for rapid field setup or integration into existing security infrastructure. The system operates on AC220V with power consumption kept under 100W, making it suitable for both mobile and fixed surveillance setups in critical zones.
Passive Spectrum Anti-Drone Detection Radar is ideal for protecting airports, power plants, government buildings, and event venues from intrusive or hostile drones. Its passive detection capability ensures that the radar does not emit signals, allowing covert surveillance while continuously monitoring the electromagnetic environment for drone communication activity.
Tactical Supply Pakistan delivers this radar as part of its specialized counter-UAV portfolio, supporting defense, intelligence, and homeland security agencies with low-profile, highly responsive detection solutions.
Can the system be integrated with other active jamming or countermeasure platforms?
Yes, it can be networked with active counter-UAV systems, providing early detection data that enables more precise and timely threat mitigation.
