Dragon 640 TL/TD/TV Lightweight Thermal Imager
Dragon 640 TL / TD / TV Lightweight Thermal Imager is an medium-range thermal imaging system delivering high-resolution detection, exceptional sensitivity, and mission-ready performance in harsh environments.
Key Features:
✔️ 640 × 480 thermal sensor with 17 µm pitch for sharp target detail
✔️ Interchangeable optics: 75 mm (TL/TD) & 100 mm (TV) lenses for flexible range coverage
✔️ Extremely low NETD for superior detection in dust, fog, and rough conditions
✔️ Integrated laser rangefinding up to ~2 km with coordinate, azimuth & elevation output
✔️ Fast start-up (~3 s) with continuous digital zoom up to ×8
✔️ Dual display (LCD/OLED 800 × 600) with white/black/color polarity modes
✔️ IP67 & MIL-STD-810F certified for military and field operations
✔️ Electronic focus, automatic calibration, and covert/standby mode
✔️ Remote-control capability; converts to tripod-mounted stationary system
✔️ Rechargeable 7.2 V battery providing 7–10 h operation; external 9–36 V DC support
✔️ Lightweight design: ~1.15 kg (net) / 1.45 kg with battery
Dragon 640 TL/TD/TV Lightweight Thermal Imager
The Dragon 640 TL/TD/TV Lightweight Thermal Imager delivers 640×480 pixel resolution through a 17 μm detector pitch sensor. It operates with lens options of 75 mm F1.3 for TL, 75 mm F1.0 for TD, and 100 mm F1.4 for TV variants. The unit weighs 1150 grams without battery and 1450 grams with the rechargeable 7.2V power pack. Frame rates switch between 9 fps and 25 fps, with export-restricted models limited to 25 fps only.
The imager features NETD below 50 mK for detecting minimal temperature differences in challenging conditions. It boots in 3 seconds and withstands temperatures from -25°C to +55°C with IP67 and MIL-STD-810F certification. Dual LCD/OLED displays show 800×600 resolution with white/black/color polarity options. Electronic focus adjusts clarity while continuous zoom extends up to 8x magnification. The integrated laser rangefinder measures targets up to 2 km and calculates coordinates, azimuth, and elevation. Battery life runs 7 to 10 hours, and external power accepts 9-36V DC input.
Border patrol units and military reconnaissance teams deploy the Dragon 640 TL/TD/TV Lightweight Thermal Imager for perimeter surveillance and target acquisition. Infantry squads use it during night operations to identify heat signatures of personnel and vehicles hidden in vegetation. Law enforcement SWAT teams scan buildings for suspects during tactical entries. Search and rescue operations locate missing persons in wilderness areas after dark. The tripod mount and remote control unit transform it into a stationary observation post for prolonged monitoring.
Tactical Supply Pakistan provides this thermal imaging system to defense and security professionals requiring reliable night vision capabilities. The company delivers equipment meeting international military standards for field operations in extreme environments.
Can the device record thermal footage for later analysis?
Yes, the composite PAL/NTSC video output connects to external recording devices for documentation and evidence collection during operations.
