Ultraviolet Rays UV Drone Camera
The Ultraviolet Rays UV Drone Camera captures 240–280 nm corona discharge signals with fused visible and thermal imaging for high-voltage inspection on Matrice 200/210/300 RTK drones.
Key Features:
✔️ Lightweight 550 g with integrated 3‑axis gimbal assembly
✔️ Ultraviolet sensor detects 240–280 nm “sunblind zone” emissions
✔️ 12 MP HD visible-light camera with 58° wide-angle lens at 1920×1080 px
✔️ Laser ranging module measures equipment distances accurately
✔️ Temperature and humidity sensors monitor atmospheric conditions
✔️ Picture-in-picture overlay fuses UV, thermal, and visible imagery
✔️ 752×574 UV video stream at 25 fps in H.264 format
✔️ Removable SD storage 32–128 GB, encrypted for secure data
✔️ PSD‑SDK integration via DJI Skyport with no external power required
✔️ Remote firmware updates and seamless Matrice 200/210/300 RTK compatibility
Ultraviolet Rays UV Drone Camera
The Ultraviolet Rays UV Drone Camera weighs 550 grams and integrates four independent sensing systems into one three-axis gimbal assembly. An ultraviolet sensor captures imagery at 240 to 280 nanometers wavelength—the “sunblind zone” where corona discharge signals dominate without solar background interference. A 12-megapixel HD camera with one-half-inch CMOS sensor and 58-degree wide-angle lens delivers simultaneous visible-light recording at 1920 by 1080 resolution. Laser ranging module provides distance measurements to equipment surfaces. An integrated temperature and humidity sensor monitors atmospheric conditions during inspection flights. Picture-in-picture overlay technology superimposes ultraviolet and thermal imagery onto real-time visible displays.
Payload Software Development Kit architecture routes data through DJI Skyport interface without requiring external power supplies or auxiliary wireless systems. A built-in high-performance processor executes fusion algorithms that align ultraviolet signals with visible imagery for precise defect localization. The 752 by 574 ultraviolet video stream operates at 25 frames per second in H.264 format. Removable SD card storage accommodates 32 to 128 gigabytes of encrypted image files. Remote firmware upgrade capability enables field updates without aircraft grounding. Seamless Matrice 200, 210, and 300 RTK platform integration connects via existing gimbal connectors.
Electric utility companies deploy the Ultraviolet Rays UV Drone Camera to detect corona discharge and high-voltage arcing along transmission lines before catastrophic failures occur. Predictive maintenance teams identify insulator degradation and flashover risks during routine condition assessments. Renewable energy operators inspect wind turbine transformers and substation equipment for electrical stress patterns. Industrial facilities monitor switchgear and circuit breaker performance under operational loads. Emergency response units assess lightning strike damage to electrical infrastructure.
Tactical Supply Pakistan provides this specialized inspection payload to utility companies and infrastructure operators requiring non-destructive electrical system diagnostics.
Why does 240-280 nanometer wavelength detect corona better than visible light imaging?
Sunblind ultraviolet zone eliminates solar background noise while corona discharge emissions peak at this wavelength. Visible light cameras cannot distinguish high-voltage arcing signals from environmental reflection.
