Small COFDM AV/BNC/HDMI/SDI Receiver
The Small COFDM AV/BNC/HDMI/SDI Receiver is a high-quality portable mini wireless AV/HDMI/SDI receiver designed for high-sensitivity video reception with robust anti-interference capabilities.
Key Features:
✔️ Latest COFDM modulation technology with 2K mode
✔️ High receiving sensitivity of less than -105 dBm at 2 meters
✔️ Wide receiving frequency range: 300 MHz to 4.4 GHz (customizable)
✔️ Supports video formats H.264 and H.265 with MPEG2 and H.264 compression
✔️ Video output options: AV, BNC, HDMI, and RJ45 (customizable)
✔️ Supports resolutions from 480i to 1080i/60
✔️ Analog stereo audio output channels
✔️ Error correction with FEC 1/2 and guard interval 1/32
✔️ Small compact size: 140x170x30 mm, weight 1.6 kg
✔️ Operating temperature range from -30°C to 55°C
✔️ Designed for drone video downlinks, vehicle surveillance, and body-worn camera
Small COFDM AV/BNC/HDMI/SDI Receiver
The Small COFDM AV/BNC/HDMI/SDI Receiver is a portable mini wireless AV/HDMI/SDI receiver that incorporates the latest COFDM modulation technology to provide unmatched receiving sensitivity of less than -105 dBm at short range. It operates over a broad frequency spectrum of 300 MHz to 4.4 GHz, which can be customized to suit specific applications. Key technical specifications include a video output supporting multiple formats (AV, BNC, HDMI, and RJ45), alongside analog stereo audio output for left and right channels. Supporting resolutions from 480i to 1080i/60, it ensures high-definition video quality for various operational demands.
The receiver supports advanced compression formats, including MPEG2 and H.264, and leverages forward error correction (FEC) 1/2 with a guard interval of 1/32 to maintain video quality in the presence of noise and interference. Its compact and lightweight design (140x170x30 mm, weighing just 1.6 kg) makes it ideal for mobile and outdoor missions. The device also possesses strong anti-interference and anti-jamming capabilities, especially in non-line-of-sight (NLOS) scenarios, which enhances reliability in demanding wireless video reception tasks.
The Small COFDM AV/BNC/HDMI/SDI Receiver, encompassing drone video downlinks, long-range vehicle surveillance, and body-worn camera video decoding. Its ability to automatically configure COFDM and decoder parameters makes it well-suited for various unmanned aerial vehicle (UAV) and security surveillance operations.
Tactical Supply Pakistan brings exceptional value to the market with the supply of top-tier tech products such as the SFGT-DR2000. Known for their commitment to quality and customer satisfaction, We ensure that our products meet the highest standards for tactical and surveillance capabilities.
What is the maximum operating frequency range of the SFGT-DR2000?
The receiver supports a customizable frequency range from 300 MHz to 4.4 GHz, allowing for flexible deployment across various wireless video transmission applications.
