Multi-Channel RF Signal Generators
Multi-Channel RF Signal Generators is a compact, high-performance RF test platform designed to simulate dense, real-world signal environments with unmatched flexibility and precision.
Key Features:
✔️ Up to 31 independent virtual RF signal generators in a single unit
✔️ Dual phase-synchronous RF outputs for diversity and MIMO testing
✔️ Aggregate bandwidth up to 320 MS/s with flexible channel assignment
✔️ Per-channel control of frequency, modulation, timing, and impairments
✔️ Integrated modulators for global digital radio, TV, and GNSS standards
✔️ Real-time RF impairment simulation for interference and stress testing
✔️ High-speed SSD streaming support for parallel signal generation (S1010)
✔️ Automated test sequencing for faster development and production cycles
The Multi-Channel RF Signal Generators operate through 31 independent virtual signal generators that process and combine signals with a cumulative bandwidth reaching 320 MS/s. Each virtual generator outputs 120 MHz blocks configurable within frequency ranges up to 3 GHz. The system features two phase-synchronous RF outputs for diversity testing scenarios and real-time impairment simulation capabilities. Users assign content, modulation type, interpolation rate, launch delay, and center frequency parameters individually to each virtual channel. The IZT S1010 variant incorporates high-speed SSD storage for parallel signal streaming in demanding applications.
The platform generates composite output signals by combining all active virtual signal generators and distributing them through dual RF outputs. Built-in modulators support global digital radio and television broadcast standards without external equipment. Universal arbitrary waveform generation functions allow custom signal creation for non-standard protocols. Automated testing sequences execute programmatically to reduce development cycles and production testing time. The compact chassis design replaces extensive multi-device setups that traditionally require separate signal generators, combiners, and distribution amplifiers.
Defense research laboratories deploy the Multi-Channel RF Signal Generators for electronic warfare system validation and radar cross-section testing. Military communication development teams use them to simulate crowded spectrum environments with interfering signals. Navy testing facilities rely on these generators for shipboard receiver qualification under realistic multi-emitter conditions. Airforce avionics labs conduct satellite navigation spoofing resistance tests using the integrated GNSS constellation simulator functionality.
Tactical Supply Pakistan offers this signal generation platform with application engineering support for complex test scenario development. The company provides training resources for defense contractors and research institutions requiring multi-channel RF capabilities.
Can this system simulate GPS jamming scenarios?
Yes, the integrated GNSS constellation simulator creates authentic satellite signals while allowing controlled interference injection to test receiver resilience against jamming and spoofing attacks in laboratory conditions.
