MIMO IP MESH Relay Node Link
The MIMO IP MESH Relay Node Link SFGT-MS0303RP is a ruggedized, high-capacity communication device designed for long-range, high-volume airborne data transmission.
Key features:
✔️ Uses FPGA architecture with multi-waveform, ultra-wideband, and high-speed frequency
✔️ Operates within a frequency range of 600 MHz to 8 GHz (customizable)
✔️ RF power: 3 x 3W output with adjustable power settings
✔️ Features COFDM modulation with multiple modulation (BPSK, QPSK, 16QAM, 64QAM)
✔️ Adjustable RF bandwidth options of 10, 20, or 40 MHz
✔️ High sensitivity of -102 dBm at 1 MHz
✔️ Transmission range over 50 kilometers line-of-sight (LOS)
✔️ Network capacity customizable to support 32, 64, or 128 nodes
✔️ IP65-rated rugged housing, shockproof and rainproof
✔️ Encryption support including AES128/256 and user-defined options
✔️ Built-in Beidou/GPS module for enhanced navigation and tracking
MIMO IP MESH Relay Node Link
The MIMO IP MESH Relay Node Link SFGT-MS0303RP integrates advanced FPGA architecture with multi-waveform and ultra-wideband technologies to deliver superior long-range communication performance. This ruggedized device uses high-speed frequency hopping mesh topology to ensure reliable data and video transmission in point-to-point, point-to-multipoint, or multipoint-to-multipoint configurations. Its flexibility allows it to form a centerless wireless broadband network efficiently without relying on base stations, making it ideal for airborne missions demanding high-volume data flow.
The SFGT-MS0303RP operates across a customizable frequency range of 600 MHz to 8 GHz and delivers potent RF power at 3 x 3 watts adjustable output configuration. Its COFDM modulation supports various constellation schemes such as BPSK, QPSK, 16QAM, and 64QAM, while flexible bandwidth options (10/20/40 MHz) cater to different data rate needs. With a high sensitivity of -102 dBm, the transceiver can sustain transmission distances over 50 kilometers in line-of-sight environments and support scalable networking with up to 128 nodes.
This device is specially designed for airborne applications requiring secure, high-capacity communication links. The MIMO IP MESH Relay Node Link enables real-time IP video input, network management, and robust control functionalities. Its IP65-rated housing offers protection against rain and shocks, making it reliable in harsh operational conditions. The built-in Beidou/GPS module enhances navigation and tracking reliability during missions.
Tactical Supply Pakistan provides this top-tier communication system, underlining their commitment to offering high-quality tactical solutions. Renowned for delivering dependable and innovative solutions, Tactical Supplies Pakistan ensures their customers have access to equipment tailored to the needs of modern defense and UAV operations.
What is the maximum transmission range of the SFGT-MS0303RP under line-of-sight conditions?
The device reliably supports transmission distances exceeding 50 kilometers in line-of-sight environments.
