IP Video Data Transceiver For Vehicle/Vessel
The IP Video Data Transceiver For Vehicle/Vessel is a high-performance duplex IP video data transceiver designed for vehicle and vessel applications, delivering reliable wireless communication with advanced COFDM modulation technology.
Key Features:
✔️ COFDM 2K modulation for robust signal transmission
✔️ Frequency Division Duplexing (FDD) for simultaneous uplink and downlink
✔️ Customizable TX and RX output frequencies between 300 MHz and 8 GHz
✔️ Powerful 43dBm (20W) adjustable RF output for long-range transmission
✔️ Supports RF bandwidths of 1/2/4/8 MHz to suit different data needs
✔️ AES 128-bit and 256-bit encryption for secure data transmission
✔️ Transfer rate of 2×30 Mbit/s via RJ45 Ethernet and 115200bps TTL serial data
✔️ Operates effectively in non-line-of-sight (NLOS) conditions at 10-20 km range
✔️ Compact and portable with dimensions 320x210x110 mm and weight 8.7 kg
✔️ Low latency performance suitable for fast-moving environments like marine vessels
IP Video Data Transceiver For Vehicle/Vessel
The IP Video Data Transceiver For Vehicle/Vessel is a duplex IP video data transceiver that uses COFDM 2K modulation to maintain stable and reliable wireless communication in challenging conditions. Moreover, it features customizable uplink and downlink frequencies from 300 MHz to 8 GHz, enabling seamless integration with various IP devices. Its FDD (Frequency Division Duplexing) technology allows simultaneous two-way communication without interference, which improves operational efficiency.
The device offers adjustable RF output power up to 20 watts (43dBm) for long-range transmission in both line-of-sight and non-line-of-sight environments. Additionally, it supports multiple RF bandwidths—1, 2, 4, and 8 MHz—to meet different data transfer requirements and optimize spectrum usage. Security is also strong, with AES 128-bit and 256-bit encryption modes and customizable password protection for all data streams.
Designed for real-world use, the IP Video Data Transceiver For Vehicle/Vessel excels in NLOS transmission across distances of 10 to 20 kilometers. Therefore, it is ideal for fast-moving applications such as marine vessel communication and point-to-point wireless networking. The device supports high transfer rates of 2×30 Mbit/s via Ethernet and synchronous 115200bps TTL serial data. Consequently, it ensures low latency and reliable end-to-end data delivery. Its compact dimensions of 320 × 210 × 110 millimeters and weight of just 8.7 kilograms make it highly portable.
Tactical Supply Pakistan proudly offers the SFGT-FD020VM as part of its premium wireless communication line. Renowned for providing technologically advanced and reliable tactical gear, we ensure customers receive equipment designed for durability and peak performance.
What is the maximum range of the SFGT-FD020VM in real-world conditions?
The SFGT-FD020VM achieves 10–20 km in NLOS conditions and up to 40 km in clear LOS scenarios. Overall, it provides dependable long-range communication for tactical and vehicular operations.
