Helicopter Carrier for Airports
This Helicopter Carrier is a mission-critical solution for fast and safe transport and deployment of helicopters in military, offshore, and emergency operations
Key Features:
✔️ Designed to lift and tow helicopters up to 5,500 kg (e.g., AB 204, 205, 206, 212)
✔️ Hydraulic lifting range from 345 mm to 782 mm for easy loading/unloading
✔️ Powered by 24 V AC tow motor (2 kW, 2000 rpm) with 24 V DC, 240 Ah battery system
✔️ Equipped with robust vulcalon wheels: 200 mm front, 300 mm rear for stable ground transfer
✔️ Hydraulic lifting and steering via 24 V DC, 3 kW power-pack ensures responsive maneuverability
✔️ Sturdy chassis with removable handles is built for harsh and varied conditions
✔️ Compact dimensions (4120 × 1650 × 345 mm) ideal for hangar and airfield operations
Helicopter Carrier for Airports (HC5500) – Engineered for secure and efficient helicopter handling
Helicopter Carrier for Airports
The Helicopter Carrier for Airports (HC5500) is a heavy-duty support vehicle designed to load, transport, and deploy helicopters safely. It features a reinforced steel platform and a hydraulic lift system that handles rotorcraft weighing up to 5,500 kg. Extendable guide rails, adjustable chocks, and tie-down fittings lock the aircraft securely in place. The dual-axle chassis and pneumatic shock-absorbing tires ensure smooth travel across ramps and hangars.
A hydraulic ramp lets a single operator raise or lower the platform gently, reducing rotor blade stress. The carrier also includes manual override controls, safety rails, and anti-slip coating for added security. Technicians can access the underside easily using quick-release panels—no need to offload the helicopter. With its self-contained power train, the HC5500 operates without relying on external energy sources.
Military bases, forward airfields, and relief zones regularly use the Helicopter Carrier for Airports (HC5500). It enables fast transitions between hangars, refueling points, and launch sites, supporting tight mission timelines. Additionally, the unit plays a key role in humanitarian missions where dependable helicopter staging accelerates evacuations, search efforts, and supply deliveries.
Tactical Supply Pakistan supports rotary aviation teams with this rugged, mobile platform to ensure secure aircraft handling across all operational stages—from deployment to maintenance.
Is the HC5500 suitable for night operations or low-visibility conditions?
Yes, its hydraulic deck edge includes LED runway lights and perimeter markers, making nighttime loading safe and efficient.
