Surface Hole Depth Gauges
Manual measuring instrument designed for rapid and accurate depth assessment of surface holes, ruts, and craters. Built with graduated measuring rods, stabilizing bases, and bubble inclinometers for reliable field use.
Key Features:
✔️ Graduated vertical rod with 0.5 cm measurement accuracy
✔️ Maximum depth range of 20 cm for surface hole evaluation
✔️ Dual bubble inclinometers ensure correct horizontal alignment
✔️ Stabilizing 3.2 cm base diameter for consistent readings
✔️ Interchangeable measuring bars: 0.95 m (1.48 kg) and 1.95 m (4.33 kg)
✔️ No complex calibration required for field deployment
✔️ Operates effectively on pavement, gravel, soil, and mixed surfaces
✔️ Used by combat engineers, naval and air force maintenance units
Surface Hole Depth Gauges
The Surface Hole Depth Gauges feature vertical measuring rods with graduated scales and stabilizing bases for accurate depth assessment of surface holes and ruts. The AM-1 model incorporates dual bubble inclinometers for horizontal positioning verification and maintains 0.5centimeter measurement accuracy across a maximum 20-centimeter range. The measuring rod base diameter measures 3.2centimeters, providing stable contact points for consistent readings on various surface materials.
Two interchangeable measuring bar configurations optimize performance for different operational conditions: 0.95-meter bars weighing 1.48 kilograms and 1.95-meter bars at 4.33 kilograms total weight. The scaled vertical rod enables rapid depth determination in pavement, gravel, soil, and other surfaces without requiring complex calibration procedures. Bubble inclinometers ensure proper device orientation during measurement operations, eliminating angular errors that compromise accuracy.
Combat engineers, naval construction battalions, and air force runway maintenance teams deploy Surface Hole Depth Gauges for infrastructure assessment and repair planning operations. Military units utilize these instruments during damage evaluation surveys, crater depth analysis, and surface preparation verification for temporary airfield construction. Field engineers rely on the gauges for determining excavation requirements and material volume calculations during defensive position construction.
Tactical Supply Pakistan provides authentic measurement instruments that meet military engineering standards for field construction applications. The company ensures each gauge undergoes rigorous calibration testing to guarantee measurement accuracy in demanding operational environments. Their logistics support maintains availability of replacement components and technical assistance for military engineering units.
Can the gauge measure depths in soft soil conditions?
Yes, the 3.2-centimeter diameter base provides sufficient surface contact area to prevent excessive penetration in soft soils while maintaining measurement stability. The base design distributes weight evenly, allowing accurate readings without the gauge sinking into loose materials.
