Fire Fighting System for Vehicles
Fire Fighting System for Vehicles— vehicle-mounted firefighting solutions with water-mist and CAFS technology for industrial, forestry, and emergency use.
Key Features:
✔️ Modular tank capacities from 200 L to 1000 L
✔️ Efficient water-mist & CAFS fire suppression
✔️ Engine-driven pumps for reliable field performance
✔️ Digital control panels with adjustable foam and monitoring
✔️ Jet and spray modes for versatile reach
✔️ Compact, low-profile designs for trucks and trailers
✔️ External water source compatible for extended operation
✔️ Rugged construction for reliable outdoor deployment
Fire Fighting System for Vehicles
The Fire Fighting System for Vehicles offers four capacity configurations spanning 100 to 1000 litres. The MPM 05 model features modular plastic tanks from 200 to 1000 litres with digital foam regulation and operates at 40 bar working pressure. The compact 300-litre variant weighs 295 kg empty and measures 1420 x 880 x 1000 mm. Both MPM variants use 2-cylinder 4-stroke petrol engines rated at 16 HP with electric and manual starters. The CAFS 400/650-litre system runs a 23 HP engine with self-priming side channel pump producing water mist droplets at 100-150 microns.
All engine-driven units deliver maximum 55 litres per minute flow rate through high-pressure diaphragm pumps. Jet mode reaches 20-22 meters while spray mode covers 7-9 meters effectively. The skid unit series from 100 to 600 litres integrates foam injection with hose lengths extending 30 to 90 meters. Each system includes maintenance-free 12V battery, 7.1-litre fuel tank, and 25-litre foam additive capacity. Operating temperature tolerance spans +5°C to +60°C across all variants. Steel frames receive double powder coating for corrosion resistance.
Forest departments in Pakistan mount Fire Fighting System for Vehicles on Hilux pickups for wildfire response in northern mountainous regions. Military airbases install the 400-litre CAFS variant on rapid intervention trucks for runway incidents. Industrial estates in Faisalabad equip Toyota Land Cruisers with 300-litre compact systems for factory perimeter patrol. Agricultural operations in Punjab deploy 600-litre skid units on tractors for crop fire control. Municipal fire brigades fit the modular 1000-litre system on light commercial vehicles for residential area coverage.
Tactical Supply Pakistan provides complete installation packages including vehicle integration, operator certification, and quarterly maintenance contracts. Their engineering team customizes mounting configurations for specific vehicle chassis requirements.
Can these systems draw water from natural sources during operation?
Yes, the MPM 05 and CAFS variants include external suction capability from lakes, rivers, and hydrants through 1.5-inch C-coupling and 3/4-inch D-coupling Storz connections, extending operational time beyond tank capacity.
