Container Dolly
Container Dolly – Durable 2‑axle dolly for streamlined, safe movement of airline containers and pallets across cargo and apron zones
Key Features:
✔️ Supports multiple Timsan models with varied ULD capacity and lengths
✔️ Low-profile, 2‑axle design optimized for ULDs like LD1, LD2, LD3
✔️ Built-in roller platform and vertical stops to assist loading/unloading via ball-bearing dec
✔️ Hot-dip galvanized or steel frame with modular construction for easy maintenance
✔️ Integrated parking brake or bar brake activated via tow bar orientation for secure holding
✔️ Tow bar and chassis control designed for tow trains and safe operation on airport ramps
✔️ Compact turning radius and maneuverable design for busy cargo apron environments
✔️ Engineered to comply with IATA, EN, and other international ground support equipment standards
Container Dolly
The Container Dolly comes in three models—CD3600, CD2500, and CD1800—engineered for safe and efficient container transport in airport and logistics zones. Deck lengths range from 1,800 mm to 3,600 mm, while the standard width of 1,900 mm ensures balanced cargo support. Each dolly rolls on pneumatic tires (7.00-15) and features a welded steel frame to handle uneven tarmac with ease. Tow height adjusts between 305 mm and 405 mm, making it compatible with various tractors.
To ensure durability, all models use corrosion-resistant steel with a powder-coated finish. Rear wheels include manual parking brakes, and welded tie-down points help secure the load. In addition, LED tail and brake lights operate through standard-compliant electrical connectors, aided by reflectors for visibility in low-light operations. Depending on the model, the dolly weighs between 450 kg and 700 kg and supports loads from 1,800 kg up to 3,600 kg.
Operators regularly deploy the Container Dolly at military bases, naval air stations, and commercial airports. It allows ground teams to move containers and heavy equipment quickly between aircraft, storage areas, and transport vehicles. Its strong frame also supports convoy towing, especially during peak activity.
Tactical Supply Pakistan strengthens aviation logistics by delivering field-tested ground support tools built for reliability, mobility, and mission-critical handling tasks.
What maintenance is required for the dollies’ pneumatic tires?
Check the tire pressure weekly and adjust to the manufacturer’s recommended PSI. This helps maintain safety and prolong tire life.
